| DIÁMETRO | PESO | ||||
| MILIMETROS | FRACCIÓN | MILESIMA | RED. | CUAD. | HEX. |
| 4.76 | 3/16 | 0.187 | 0.14 | 0.178 | 0.154 |
| 6.35 | 1/4 | 0.25 | 0.248 | 0.316 | 0.274 |
| 7.94 | 5/16 | 0.312 | 0.388 | 0.496 | 0.428 |
| 9.53 | 3/8 | 0.375 | 0.559 | 0.712 | 0.616 |
| 11.11 | 7/16 | 0.437 | 0.761 | 0.964 | 0.839 |
| 12.7 | 1/2 | 0.5 | 0.994 | 1.265 | 1.09 |
| 14.29 | 9/16 | 0.562 | 1.25 | 1.601 | 1.387 |
| 15.87 | 5/8 | 0.625 | 1.552 | 1.976 | 1.712 |
| 17.46 | 11/16 | 0.687 | 1.878 | 2.393 | 2.072 |
| 19.05 | 3/4 | 0.75 | 2.235 | 2.847 | 2.465 |
| 20.64 | 13/16 | 0.812 | 2.624 | 3.341 | 2.893 |
| 22.22 | 7/8 | 0.875 | 3.042 | 3.874 | 3.355 |
| 23.81 | 15/16 | 0.937 | 3.493 | 4.449 | 3.852 |
| 25.4 | 1 | 1 | 3.974 | 05.06 | 4.383 |
| 26.99 | 1 1/16 | 1.062 | 4.486 | 5.712 | 4.947 |
| 28.57 | 1 1/8 | 1.125 | 5.029 | 6.404 | 5.547 |
| 30.16 | 1 3/16 | 1.187 | 5.605 | 7.138 | 6.179 |
| 31.75 | 1 1/4 | 1.25 | 6.211 | 7.908 | 6.848 |
| 33.34 | 1 5/16 | 1.312 | 6.846 | 8.717 | 7.549 |
| 34.92 | 1 3/8 | 1.375 | 7.47 | 9.567 | 8.285 |
| 36.51 | 1 7/16 | 1.437 | 8.212 | 10.46 | 9.058 |
| 38.1 | 1 1/2 | 1.5 | 8.942 | 11.39 | 9.86 |
| 39.69 | 1 9/16 | 1.562 | 9.704 | 12.35 | – |
| 41.27 | 1 5/8 | 1.625 | 10.49 | 13.31 | – |
| 42.86 | 1 11/16 | 1.687 | 11.32 | 14.41 | – |
| 44.45 | 1 3/4 | 1.75 | 12.17 | 15.4 | – |
| 46.04 | 1 13/16 | 1.812 | 13.06 | 16.62 | – |
| 47.62 | 1 7/8 | 1.875 | 13.97 | 17.79 | – |
| 49.21 | 1 15/16 | 1.937 | 14.91 | 18.99 | – |
| 50.8 | 2 | 2 | 15.9 | 20.24 | – |
| 52.39 | 2 1/16 | 2.062 | 16.91 | 21.52 | – |
| 52.39 | 2 1/8 | 2.125 | 17.95 | 22.85 | – |
| 55.56 | 2 3/16 | 2.187 | 19 | 24.21 | – |
| 57.15 | 2 1/4 | 2.25 | 20.1 | 25.63 | – |
| 58.74 | 2 5/16 | 2.312 | 21.3 | 27.07 | – |
| 60.32 | 2 3/8 | 2.375 | 22.4 | 28.55 | – |
| 61.91 | 2 7/16 | 2.437 | 23.6 | 30.06 | – |
| 635 | 2 1/2 | 2.5 | 24.8 | 31.63 | – |
| 65.07 | 2 9/16 | 2.562 | 26.1 | 33.23 | – |
| 66.67 | 2 5/8 | 2.625 | 27.4 | 34.87 | – |
| 68.28 | 2 11/16 | 2.687 | 28.7 | 36.55 | – |
| 69.85 | 2 3/4 | 2.75 | 30.1 | 37.21 | – |
| 71.44 | 2 13/16 | 2.812 | 31.4 | 40.03 | – |
| 73.02 | 2 7/8 | 2.875 | 32.9 | 41.82 | – |
| 74.61 | 2 15/16 | 2.937 | 34.3 | 43.63 | – |
| 76.2 | 3 | 3 | 35.8 | 45.54 | – |
| 77.77 | 3 1/16 | 3.062 | 37.3 | 47.37 | – |
| 79.37 | 3 1/8 | 3.125 | 38.8 | 49.41 | – |
| 80.96 | 3 3/16 | 3.187 | 40.4 | 51.52 | – |
| 82.55 | 3 1/4 | 3.25 | 42 | 53.46 | – |
| 84.18 | 3 3/16 | 3.312 | 43.6 | 55.53 | – |
| 85.72 | 3 3/8 | 3.375 | 45.3 | 57.64 | – |
| 87.31 | 3 7/16 | 3.437 | 47 | 59.8 | – |
| 88.9 | 3 1/2 | 3.5 | 48.7 | 61.99 | – |
| 90.47 | 3 9/16 | 3.562 | 50.5 | 64.21 | – |
| 92.07 | 3 5/8 | 3.625 | 52.2 | 66.5 | – |
| 93.66 | 3 11/16 | 3.687 | 54 | 68.82 | – |
| 95.25 | 3 3/4 | 3.75 | 55.9 | 71.17 | – |
| 96.84 | 3 13/16 | 3.812 | 57.8 | 73.55 | – |
| 98.42 | 3 7/8 | 3.875 | 59.7 | 75.98 | – |
| 100.01 | 3 15/16 | 3.937 | 61.6 | 76.96 | – |
| 101.6 | 4 | 4 | 63.6 | 80.96 | – |
| PULIDO (SEMIFLECHA) | ||
| PULG. | MM. | KG/ML |
| 3/16 | 4.8 | 0.14 |
| 1/4 | 6.3 | 0.25 |
| 5/16 | 7.9 | 0.39 |
| 3/8 | 9.53 | 0.56 |
| 1/2 | 12.7 | 1 |
