Peso aproximado (kg./m2) de la rejilla de acero electroforjada.
| SOLERA DE CARGA | |||||||
| MILIMETROS | PULGADAS | IS-01 | IS-02 | IS-03 | IS-04 | IS-05 | IS-06 |
| 3.2x 19.1 | 1/8″ X 3/4″ | 26.2 | 29.1 | 22.9 | 25.8 | 19.1 | 22 |
| 3.2 X 25.4 | 1/8″ X 1″ | 33.9 | 36.9 | 29.5 | 32.4 | 24.4 | 27.4 |
| 3.2x 31.8 | 1/8″ X 1-1/4″ | 41.7 | 44.6 | 36.1 | 39.1 | 29.8 | 32.8 |
| 3.2 X 38.1 | 1/8″ X 1-1/2″ | 49.4 | 52.4 | 42.8 | 45.7 | 35.2 | 38.1 |
| 4.8x 19.1 | 3/16″ X 3/4″ | 37.8 | 40.7 | 32.8 | 35.8 | 27.1 | 30.1 |
| 4.8 X 25.4 | 3/16″ X 1″ | 49.4 | 52.4 | 42.8 | 45.7 | 35.2 | 38.1 |
| 4.8x 31.8 | 3/16″x1-1/4″ | 61.1 | 64 | 52.7 | 55.7 | 43.3 | 46.2 |
| 4.8 X 38.1 | 3/16″x1-1/2″ | 72.7 | 75.6 | 62.7 | 65.7 | 51.3 | 54.3 |
| 4.8 X 44.4 | 3/16″x1-3/4″ | 84.6 | 87.8 | 72.9 | 76.2 | 59.7 | 62.9 |
| 4.8 X 50.8 | 3/16″ X 2″ | 96.2 | 99.4 | 82.9 | 86.1 | 67.7 | 70.9 |
| 4.8 X 57.1 | 3/16″x2-1 /4″ | 107.8 | 111 | 92.9 | 96.1 | 75.8 | 79 |
| 4.8 X 63.5 | 3/16″x2-1/2″ | 119.4 | 122.6 | 102.8 | 106 | 83.9 | 87.1 |
